| ราคาปกติ |
|
27,500.00 |
| ราคาพิเศษ |
|
19,500.00 |
| รวมภาษี |
|
20,865.00 |
| ลดไป |
|
29.09 % |
|
|
|
- Eaton 5PX 1500i RT2U G2
- Topology : Line-Interactive High Frequency (Pure Sinewave, Booster + Fader)
- Format : RT2U (tower / rack 2U)
- Rating (VA/Watts) : 1500VA / 1500W
- Connection :
- - Input : IEC C14 (10A)
- - Outputs : 8 x IEC C13 (10A)
- - Remote controlled sockets : 2 groups of 2 x IEC C13 (10 A)
- Input Voltage Without Using Batteries : 160V-294V (adjustable to 150V-294V)
- Input frequency Range Without Using Batteries : 47 to 70 Hz (50 Hz system), 56.5 to 70 Hz (60 Hz system), 40 Hz in low-sensitivity mode
- Output Voltages : 230 V (+6/-10 %) (Adjustable to 200V* / 208V / 220V / 230V / 240V)
- Output Frequency : 50/60 Hz +/- 0.1 Hz (autosensing)
- Communication Ports :
- - 1 USB port + 1 serial RS232 port + 1 mini-terminal block for Remote ON/OFF
- - 1 mini-terminal block for Remote Power OFF + 1 mini-terminal block for output relay
- Communication slot : 1 slot for Network M2 (included in Netpack version), INDGW-M2 or Relay-MS cards
- Dimensions W x D x H / Weight : 438x448x85.5 mm / 27.8kg
- Warranty : 3Years On-Site
|
|
|
|
|
|
|
 |
| |
|
|
| ราคาปกติ |
|
27,130.00 |
| ราคาพิเศษ |
|
23,600.00 |
| รวมภาษี |
|
25,252.00 |
| ลดไป |
|
13.01 % |
|
|
|
- Eaton 5PX 1500i RT2U
- Topology : Line-Interactive High Frequency (Pure Sinewave, Booster + Fader)
- Configuration : Tower/Rack 2U
- Rating (VA/Watts) : 1500VA/1350W
- Connection :
- - Input : 1 IEC C14 (10A)
- - Outputs : 8 IEC C13 (10A)
- - Switched Outlet Group : 2 outlet groups
- Input Voltage Without Using Batteries : 160V-294V (adjustable to 150V-294V) 47 to 70Hz (50 Hz system)
- Input frequency Range Without Using Batteries : 56.5 to 70 Hz (60 Hz system), 40 Hz in low-sensitivity mode
- Output Voltages : 230 V (+6/-10 %) Adjustable to 200V / 208V / 220V / 230V / 240V)
- Output Frequency : 50/60 Hz +/- 0.1 % (autosensing)
- Communication Ports :
- - 1 USB port + 1 RS232 serial port and relay contacts (USB and RS232 ports cannot be used simultaneously)
- - 1 mini-terminal block for remote ON/OFF and Remote Power Off
- Communications Card Slots : 1 slot for Network-MS card, ModBus-MS or Relay-MS cards
- Dimensions H x W x D / Weight : 441 x 522 x 86.2 (2U) mm / 27.6kg
- Warranty : 3 Years On-Site Service by Eaton (Thailand)
|
|
|
|
|
|
|
 |
| |
|
|
| ราคาปกติ |
|
40,120.00 |
| ราคาพิเศษ |
|
31,500.00 |
| รวมภาษี |
|
33,705.00 |
| ลดไป |
|
21.49 % |
|
|
|
- Eaton 5PX 2200i RT2U UPS
- Topology : Line-Interactive High Frequency (Pure Sinewave, Booster + Fader)
- Configuration : Tower/Rack 2U
- Rating (VA/Watts) : 2200VA/1980W
- Connection :
- - Input : 1 IEC C14 (10A)
- - Outputs : 8 IEC C13 (10A) + 1 IEC C19 (16A)
- Input Voltage Without Using Batteries : 160V-294V (adjustable to 150V-294V) 47 to 70Hz (50 Hz system)
- Input frequency Range Without Using Batteries : 56.5 to 70 Hz (60 Hz system), 40 Hz in low-sensitivity mode
- Output Voltages : 230 V (+6/-10 %) Adjustable to 200V / 208V / 220V / 230V / 240V)
- Output Frequency : 50/60 Hz +/- 0.1 % (autosensing)
- Communication Ports :
- - 1 USB port + 1 RS232 serial port and relay contacts (USB and RS232 ports cannot be used simultaneously)
- - 1 mini-terminal block for remote ON/OFF and Remote Power Off
- Communications Card Slots : 1 slot for Network-MS card, ModBus-MS or Relay-MS cards
- Dimensions H x W x D / Weight : 441 x 522 x 86.2 (2U) mm / 28.5 kg
- Warranty : 3 Years On-Site Service by Eaton (Thailand)
|
|
|
|
|
|
|
|
| |
|
|
| ราคาปกติ |
|
36,900.00 |
| ราคาพิเศษ |
|
33,000.00 |
| รวมภาษี |
|
35,310.00 |
| ลดไป |
|
10.57 % |
|
|
|
- Eaton 5PX 2200i RT2U G2
- Topology : Line-Interactive High Frequency (Pure Sinewave, Booster + Fader)
- Format : RT2U & RT3U
- Rating (VA/Watts) : 2200VA / 2200W
- Connection :
- - Input : IEC C20 (16A)
- - Outputs : 8 x IEC C13 (10A), 2 x IEC C19 (16A)
- - Remote controlled sockets : 1 group of 2 x IEC C13 (10 A), 1 group of 2 x IEC C13 (10 A) + 1 x IEC C19 (16A)
- Input Voltage Without Using Batteries : 160V-294V (adjustable to 150V-294V)
- Input frequency Range Without Using Batteries : 47 to 70 Hz (50 Hz system), 56.5 to 70 Hz (60 Hz system), 40 Hz in low-sensitivity mode
- Output Voltages : 230 V (+6/-10 %) (Adjustable to 200V* / 208V / 220V / 230V / 240V)
- Output Frequency : 50/60 Hz +/- 0.1 Hz (autosensing)
- Communication Ports :
- - 1 USB port + 1 serial RS232 port + 1 mini-terminal block for Remote ON/OFF
- - 1 mini-terminal block for Remote Power OFF + 1 mini-terminal block for output relay
- Communication slot : 1 slot for Network M2 (included in Netpack version), INDGW-M2 or Relay-MS cards
- Dimensions W x D x H / Weight : 438x603x85.5 (RT2U), 438x483x129 (RT3U) / 40.4 (RT2U), 39.7 (RT3U)
- Warranty : 3Years On-Site
|
|
|
|
|
|
|
|
| |
|
|
| ราคาปกติ |
|
51,770.00 |
| ราคาพิเศษ |
|
40,000.00 |
| รวมภาษี |
|
42,800.00 |
| ลดไป |
|
22.74 % |
|
|
|
- Eaton 5PX 3000i RT2U UPS
- Topology : Line-Interactive High Frequency (Pure Sinewave, Booster + Fader)
- Configuration : RT2U and RT3U
- Rating (VA/Watts) : 3000VA/2700W
- Connection :
- - Input : 1 IEC C14 (10A)
- - Outputs : 8 IEC C13 (10A) + 1 IEC C19 (16A)
- Input Voltage Without Using Batteries : 160V-294V (adjustable to 150V-294V) 47 to 70Hz (50 Hz system)
- Input frequency Range Without Using Batteries : 56.5 to 70 Hz (60 Hz system), 40 Hz in low-sensitivity mode
- Output Voltages : 230 V (+6/-10 %) Adjustable to 200V / 208V / 220V / 230V / 240V)
- Output Frequency : 50/60 Hz +/- 0.1 % (autosensing)
- Communication Ports :
- - 1 USB port + 1 RS232 serial port and relay contacts (USB and RS232 ports cannot be used simultaneously)
- - 1 mini-terminal block for remote ON/OFF and Remote Power Off
- Communications Card Slots : 1 slot for Network-MS card, ModBus-MS or Relay-MS cards
- Dimensions H x W x D / Weight : 441 x 647 x 86.2 (RT2U) mm / 38.08 kg
- Warranty : 3 Years On-Site Service by Eaton (Thailand)
|
|
|
|
|
|
|
|
| |
|
|
| ราคาปกติ |
|
48,000.00 |
| ราคาพิเศษ |
|
43,500.00 |
| รวมภาษี |
|
46,545.00 |
| ลดไป |
|
9.38 % |
|
|
|
- Eaton 5PX 3000i RT2U G2
- Topology : Line-Interactive High Frequency (Pure Sinewave, Booster + Fader)
- Format : RT2U & RT3U
- Rating (VA/Watts) : 3000VA / 3000W
- Connection :
- - Input : IEC C20 (16A)
- - Outputs : 8 x IEC C13 (10A), 2 x IEC C19 (16A)
- - Remote controlled sockets : 1 group of 2 x IEC C13 (10 A), 1 group of 2 x IEC C13 (10 A) + 1 x IEC C19 (16A)
- Input Voltage Without Using Batteries : 160V-294V (adjustable to 150V-294V)
- Input frequency Range Without Using Batteries : 47 to 70 Hz (50 Hz system), 56.5 to 70 Hz (60 Hz system), 40 Hz in low-sensitivity mode
- Output Voltages : 230 V (+6/-10 %) (Adjustable to 200V* / 208V / 220V / 230V / 240V)
- Output Frequency : 50/60 Hz +/- 0.1 Hz (autosensing)
- Communication Ports :
- - 1 USB port + 1 serial RS232 port + 1 mini-terminal block for Remote ON/OFF
- - 1 mini-terminal block for Remote Power OFF + 1 mini-terminal block for output relay
- Communication slot : 1 slot for Network M2 (included in Netpack version), INDGW-M2 or Relay-MS cards
- Dimensions W x D x H / Weight : 438x603x85.5 (RT2U), 438x483x129 (RT3U) / 40.4 (RT2U), 39.7 (RT3U)
- Warranty : 3Years On-Site
|
|
|
|
|
|
|
|
