ITEM DESCRIPTION
Output
Output power capacity : 325Watts / 625VA
Max Configurable Power (Watts) : 325Watts / 625VA
Nominal Output Voltage : 230V
Efficiency at Full Load : 65.3 %
Output Frequency (sync to mains) : 50/60 Hz +/-1 Hz
Topology : Line Interactive
Waveform type : Square wave
Output Connections : (3) Universal Receptacle (Battery Backup)
Transfer Time : 4ms typical : 8ms maximum
Input
Nominal Input Voltage : 230V
Input frequency : 45 - 65 Hz
Input Connections : IEC-320-C14
Cord Length : 1.22meters
Input voltage range for main operations : 151 - 299V
Number of Power Cords : 1
Efficiency at Full Load : 65.3 %
Type of Input Protection Required : 3-pole breaker
Maximum Input Current : 3.0A
Batteries & Runtime
Battery type : Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules : 1
Typical recharge time : 6 hour(s)
Replacement Battery : APCRBC110
Expected Battery Life (years) : 2 - 4
Surge Protection and Filtering
Surge energy rating : 273 Joules
Physical
Color : Black
Maximum Depth : 88mm , 8.85cm
Maximum Height : 278mm , 27.85cm
Maximum Width : 160mm , 16.0cm
Net Weight : 5.0kg
Shipping Depth : 128mm , 12.8cm
Shipping Height : 399mm , 39.9cm
Shipping Width : 215mm , 21.5cm
Shipping weight : 5.2kg
Master Carton Units : 1.0
Units per Pallet : 100.0
Environmental
Operating Environment : 0 - 40 °C
Operating Relative Humidity : 0 - 95 %
Storage Temperature : -15 - 40 °C
Storage Relative Humidity : 0 - 95 %
Audible noise at 1 meter from surface of unit : 45.0dBA
Conformance
Equipment protection policy : No EPP for ASEAN
Standard warranty : 2-Year On-Site Warranty by SCHNEIDER ELECTRIC CPCS (THAILAND)
Sustainable Offer Status
RoHS : Compliant
REACH : REACH: Contains No SVHCs
|
 |
|
 |
|
